5 1 Upmix Software Development 4,7/5 2240votes
5 1 Upmix Software Developer. 5 1 Upmix Software Developer. Key features include the native C/C++ compiler, advanced graphical plotting tools, statistical profiling, and the Visual. DSP++ kernel (VDK), which allows a user's code to be implemented in a more structured and easier- to- scale manner.
The ADSP-21469 EZ-KIT Lite® provides developers with a cost-effective method for initial evaluation of the ADSP-2146x SHARC® Processors via a USB-based, PC-hosted tool set. With this EZ-KIT Lite, users can learn more about the Analog Devices (ADI) ADSP-21469 hardware and software development, and quickly prototype a wide range of applications. The EZ-KIT Lite includes an ADSP-21469 SHARC Processor desktop evaluation board along with an evaluation suite of the VisualDSP++® development and debugging environment, including the C/C++ compiler, assembler, and linker.
The evaluation suite of VisualDSP++ is designed to be used with the EZ-KIT Lite only. The EZ-KIT Lite also comes with a standalone debug agent board that is removable to allow a user to plug-in an external emulator.
Ordering Information: Part number: ADZS-21469-EZLITE CROSSCORE® Tools Support: Tel: 1-800-ANALOGD (262-5643). This EZKIT is supported by both the CrossCore® Embedded Studio and VisualDSP++ development environments. Please download the or the for the latest information about System Requirements. Pages viewed will be listed here.
64 MB of dedicated found on the Fatal1ty Pro sound card via two 48LC32M8A2-75 C (PC133) chips The top-end Elite Pro model was aimed at musicians, bundled with the X-Fi external I/O box (offering phono with preamp inputs for turntables, high-impedance input for guitars, 1⁄ 4 inch mic input, headphone output, line-in, and full size MIDI I/O, as well as optical and RCA Coaxial digital inputs and outputs), and remote control. The Platinum and Fatal1ty FPS models both offer a front-panel drive-bay control unit and remote control, while the base model was supplied without any such accessories. All but the top model claimed 109 dB, while the Elite Pro model uses a higher-end, with 116 dB claimed. The bottom two models feature 2 MB standard RAM, while the top models offer 64MB of X-RAM, designed for use in games to store sound samples for improved gaming performance. October 2006 saw a minor rebranding: the X-Fi XtremeMusic edition, which was in fact a highly capable gaming card, as it offers hardware decoding and EAX support, was replaced with the XtremeGamer model. The revised model featured half-width PCB, non-gold-plated connectors, optical out instead of the digital out and digital I/O module jack, and lacked the connector for users wishing to purchase a separate X-Fi I/O box. Functionality is otherwise the same.
The market segment occupied by the XtremeMusic was moved downwards, with the introduction of the (cheaper) 'Xtreme Audio' and 'Xtreme Audio Notebook' products, which, despite the 'X-Fi' label, are the only products in the X-Fi line not using the EMU20K1 chip ( CA20K1) but an older chip similar to the Audigy SE and SB Live! Cards ( CA0106-WBTLF) and thus lacking the hardware acceleration of 3D sound and EAX sound effects, gaming and content creation features and the I/O extensibility of all the other X-Fi models.
The other new product introduced was the X-Fi 'XtremeGamer Fatal1ty Pro', identical in function to the Fatal1ty FPS, but made more affordable by the unbundling of the I/O panel and remote control. The 20K1 chip can use a significant amount of to store sound effects for faster and improved processing, just like the previous E-mu 10K-series and E-mu 8000. This feature, dubbed X-RAM by Creative and found on the higher-end models in the X-Fi line (the Elite Pro, Fatal1ty and XtremeGamer Fatal1ty Pro Series), is claimed to offer quality improvement through audio processing capability enhancement, in addition to further reduction in host system CPU overhead. In 2007, Creative Technology unveiled x1 and /34 versions of Sound Blaster X-Fi Xtreme Audio. ExpressCard Sound Blaster X-Fi for Notebooks (34 mm with a removable plastic adapter for 54 mm slots). X-Fi USB products [ ] In addition to PCI and PCIe internal sound cards, Creative also released an external USB-based solution (named X-Mod) in November 2006 which is listed in the same category as the rest of the X-Fi lineup, but is only a stereo device, marketed to improve music playing from laptop computers, and with lower specifications of the internal offerings.
Other external products that use X-Fi name include USB-based Sound Blaster X-Fi HD, Sound Blaster X-Fi Surround 5.1 Pro, and Sound Blaster X-Fi Go! Pro, their internal hardware components are different for various usages and needs for gaming, surround, or audiophile standards X-Fi features [ ]. 4-channel stereo multiplexed WM8775SEDS placed on X-Fi Fatal1ty Pro The audio processor on X-Fi was the most powerful at its time of release, offering an extremely robust sample rate conversion () engine in addition to enhanced internal sound channel routing options and greater 3D audio enhancement capabilities. A significant portion of the audio processing unit was devoted to this resampling engine. The SRC engine was far more capable than previous Creative sound card offerings, a limitation that had been a major thorn in Creative's side. Most digital audio is at 44.1 kHz, a standard no doubt related to, while sound cards were often designed to process audio at 48 kHz.
So, the 44.1 kHz audio must be resampled to 48 kHz (Creative's previous cards' operated at 48 kHz) for the audio DSP to be able to process and affect it. A poor resampling implementation introduces artifacts into the audio which can be heard, and measured as higher, within higher frequencies (generally 16 kHz and up).
X-Fi's resampling engine produces a near-lossless-quality result, far exceeding any known audio card available at the time of release. This functionality is used not only for simple audio playback, but for several other features of the card such as the 'Crystalizer', a technology that claims to improve the clarity of digital music through digital analysis (supported by all X-Fi models, including the Xtreme Audio and X-Mod).
The Sound Blaster X-Fi presents the following features, which are usually implemented with the aid of the X-Fi DSP or in software, in the Xtreme Audio model. Since its release X-Fi has caused several unsolved problems with sound glitches on various motherboards.
Crystalizer [ ] Creative Labs states that the primary function of the Crystalizer is to 'restore portions of the sound which were lost during compression'. The 'compression' that is meant here is not the digital file-size reduction achieved by digital technologies like for example. Rather, the idea is to reverse the effects of, an analog technique that was and is used during the production of most 1990s and newer (with the exception of some recordings) to make them sound louder at the same volume level setting, as it was found that subjectively louder CDs get more airplay and sell better. To achieve this loudness without introducing strong, points in the signal where the volume reaches a maximum are compressed (which means in this case: reduced in volume), then the whole signal is multiplied by a factor so that the maximum volume is reached again. After this, the music as a whole is louder than it was before, but the maximum volume points (mostly ) are not as pronounced as they were before. Since this whole process is done before the final Audio CD is recorded, its effect is equally present in uncompressed audio files created from such a CD, in compressed audio made from the CD, as well as in compressed audio from that same CD.
Transients are typically found in sounds, in of voice recordings, and during the first few milliseconds (the so-called attack phase) of non-percussive instrument sounds. All these tend to be somewhat muffled by dynamic range compression. To undo this effect, the Crystalizer uses a multiband (compressor/expander) with dynamically adjusted compression/expansion. Its main function is to detect transients and to increase their relative volume level. As a consequence of enabling the Crystalizer, the signal is altered, and whether the result improves upon the input audio is purely a matter of perception and can depend on the type of audio being played.
CMSS-3D [ ] 'CMSS-3D recreates realistic surround sound from any audio source and puts you right in the center of the action, whether you are using multichannel speakers or headphones.' CMSS-3D is a DSP feature that provides audio enhancement. Depending on the equipment used, CMSS-3D has 3 variants: • CMSS-3D Headphone: When the Creative Control Panel is set to Headphones, this setting creates virtual 3D positional audio via synthesized binaural cues (see and ).
If the application generating the audio uses a hardware-accelerated 3D audio API (i.e. DirectSound3D or OpenAL), the input for the binaural synthesis algorithms consists of up to 128 sound sources positioned arbitrarily in 3D space, this is the most accurate utilisation of CMSS-3D. If the application instead generates multi-channel sound directly (e.g. A media player app or a game with software-based audio processing), the input for the binaural synthesis algorithms consist of the 4 to 7 positional sound sources associated with the application's selected speaker configuration. Such applications may use the Speakers settings defined by Windows in which case it is possible to set the Windows Speakers configuration to a multichannel set-up, e.g. 5.1, so that the application will output multi channel audio. • CMSS-3D Virtual (Stereo Xpand): When the Creative Control Panel is set to 2/2.1 or 4/4.1 speakers, this setting creates virtual 3D positional audio similar to CMSS-3DHeadphone.
The difference is that this includes techniques such as crosstalk cancellation because sound from all speakers reaches BOTH ears which makes the binaural cues more complicated to synthesize. Additionally, the listener must be located in the 'sweet spot' between all of the speakers for the effect to work properly. Note that this is not available (including MacroFX and ElevationFilter) when using 5.1 or more speakers. In these cases, 3D audio sources are mapped to speakers by manipulating the relative volume levels for the different speaker positions.
Hardware accelerated 3D-audio is still handled as positional audio but translated using the more complex binaural algorithms. Note that more recent driver versions force the synchronisation between Windows Speakers configuration and the X-Fi control panel when this was previously optional so unlike CMSS-3D Headphone some multi-channel applications will not make use of the technology.
• CMSS-3D Surround: When the Creative Control Panel is set to 4/4.1, 5.1, 6.1, or 7.1 speakers, this setting will upmix stereo sources to multiple channels. Note that both CMSS-3DSurround and CMSS-3DVirtual can be enabled when using 4/4.1 speakers. As above hardware-accelerated 3D audio will be translated to the number of channels specified. MacroFX [ ] Enabling this setting will apply special filtering algorithms in order to improve localization for sound sources located very close to the listener. ElevationFilter [ ] Enabling this setting will apply special filtering algorithms in order to improve localization for sound sources located above or below the listener.
EAX effects [ ] is designed to be enabled by game developers within a game to enhance the 'simulated-reality' the user is experiencing; for example, the ringing of game-world swords will sound differently depending on whether the protagonist is currently in a game-world temple vault or in a game-world open field. There are also 8 built-in EAX effects which can be enabled by the user. SVM [ ] This is Smart Volume Management.
It is a that evens out the dynamic range of any given source so that quieter sounds are louder and loud sounds are quiet. It is best used in circumstances where noise disturbance might be an issue, Late at night for instance. Otherwise it is generally preferable to have it disabled as it does make the sound less dynamic and you don't get the full impact of loud parts in films, music also sounds less lively. Graphic Equalizer [ ] This function divides music into ten frequency bands, which can be adjusted using the sliders. Johnny Juliano Beat Vault Instrumentals Forever. Mixer [ ] There are multiple volume adjustments for different inputs and outputs on the system. The master volume affects all of these settings.
The default and recommended value is 50% for all sources, which actually equates to a 0 dB amplification (none), while a 100% value causes a 16 dB amplification. MIDI support [ ] As with many of Creative's previous sound cards, the X-Fi supports. Additionally, the Audio Creation Mode of the card allows the use of in playback via the use of controllers. Dolby Digital bitstream out [ ] This setting controls the DD sound encoder. DTS (Digital Theater Systems) bitstream out [ ] This setting is the same as Dolby Digital Bitstream Out, only with DTS sound instead. Operating system support [ ] Although Creative was slow to embrace 64-bit drivers for the X-Fi lineup, most x86-64 architecture based operating systems are now supported.
Microsoft Windows 7 includes basic driver support for many of the X-Fi series cards. Many of the X-Fi features however require the software applications provided by Creative in order to utilize the full capabilities of the hardware. Linux support [ ] On September 24, 2007 Creative Labs released a unsupported beta driver providing Linux 64-bit OS support for the following Sound Blaster X-Fi series sound cards: • Creative Sound Blaster X-Fi Elite Pro • Creative Sound Blaster X-Fi Platinum • Creative Sound Blaster X-Fi Fatal1ty • Creative Sound Blaster X-Fi XtremeGamer • Creative Sound Blaster X-Fi XtremeMusic An driver is available with v4 build 1013 and above. Datasheets were provided by Creative to enable driver development. On November 6, 2008 Creative finally released their driver under a GPL license. It supports x86 as well as x86-64 architectures and is listed in their support area.
On May 15, 2009 after some communications with Creative, developer Takashi Iwai finally got a mergeable version of their X-Fi driver. On August 31, 2009 the driver (snd-ctxfi) was included in release of ALSA 1.0.21.
Support for Creative Sound Blaster X-Fi Titanium HD was added on January 25, 2012 in ALSA v1.0.25 release. Xtreme Audio that has a different chipset stayed unsupported for longer time. It is currently supported by advanced Linux ALSA driver modules but might require installation of additional packages from alternative repositories. X-Fi MB as a pure software solution has Windows as a system requirement and thus does not provide Linux support. X-Fi line-up [ ] X-Fi MB [ ] X-Fi MB is a software solution that enables basic X-Fi features on computers with integrated audio into an X-Fi device.
It requires some degree of driver support from the audio hardware manufacturer. X-Fi MB is commonly bundled with motherboards and computer systems, and is comparable to an X-Fi XtremeAudio.
Bundled with some and motherboards, the X-Fi MB is sold as X-Fi Supreme FX and is actually a standard integrated HD audio codec paired with X-Fi MB. The X-Fi features are implemented entirely in the software. Other hardware vendors sell the X-Fi MB solution simply as Sound Blaster X-Fi Integrated Sound. X-Fi MB is available in different versions e.g. X-Fi MB, X-Fi MB2, X-Fi MB3 and X-Fi MB5. The current version available on select laptops and desktops is X-Fi MB5. X-Fi Xtreme Audio [ ] The entry-level model of the X-Fi series, the Sound Blaster X-Fi Xtreme Audio, does not actually have the EMU20K1 chip but is a re-branded, using the same family of chips (CA0106-WBTLF), and even the same drivers.
Thus, not only is all of the X-Fi–related processing performed in software, but it also lacks basic hardware acceleration just like the SB Live! 24-bit, the Audigy SE and other budget Soundblaster models. The X-Fi Xtreme Audio does not use the same drivers as the rest of the X-Fi family (and lacks ASIO), some games do not recognize it as being 'X-Fi capable hardware', and the device's hardware profile resembles that of older Live! And Audigy cards. Products in the X-Fi Family [ ] Card Release Interface Chip I/O Console I/O Drive Box Remote control Notes Elite Pro Aug 2005 116 dB PCI EMU20K1 64 MB included - included Additional software included. Fatal1ty Aug 2005 109 dB PCI EMU20K1 64 MB optional included included Also known as 'Fatal1ty FPS' and 'Fatal1ty Edition'.
Platinum Aug 2005 109 dB PCI EMU20K1 2 MB optional included included Platinum Fatal1ty Champion Aug 2005 109 dB PCI EMU20K1 64 MB optional included included Rebranded 'Fatal1ty' card. XtremeMusic Aug 2005 109 dB PCI EMU20K1 2 MB optional optional optional Digital Audio Sep 2005 109 dB PCI EMU20K1 2 MB optional optional optional Japan-only variant of XtremeMusic with additional jack extension. Xtreme Audio Oct 2006 104 dB PCI CA0106 - - - optional card.
Does not use the EMU20K1 chipset used in the rest of the series but an old one used in the Audigy SE, Audigy Value and SB Live! It also has Crystallizer and CMSS-3D. Xtreme Audio PCI Express Oct 2006 108 dB PCIe CA0110 - - - optional Same as the Xtreme Audio, however in a PCIe format with a CA0110 chipset, and slightly increased SNR. XtremeGamer Oct 2006 109 dB PCI EMU20K1 2 MB - - optional card. Replacement for XtremeMusic. XtremeGamer Fatal1ty Pro Oct 2006 109 dB PCI EMU20K1 64 MB optional optional optional Essentially the Original Fatal1ty/Fatal1ty Edition/Fatal1ty FPS/Platinum Fatal1ty Champion card without the I/O drive box and remote control. Titanium Fatal1ty Champion Jun 2008 109 dB PCIe EMU20K2 64 MB - included optional Titanium Fatal1ty Professional Jun 2008 109 dB PCIe EMU20K2 64MB - optional optional Essentially a Titanium Fatal1ty Champion card without the I/O drive box.
Titanium Professional Audio PCI Express Jun 2008 109 dB PCIe EMU20K2 16 MB - - optional Asia-only variant of X-Fi Titanium with minijack-to-2RCA cable and EMI shield Titanium Sep 2008 109 dB PCIe EMU20K2 16 MB - - optional First X-Fi card for which Creative made available a software-based implementation of to allow for real-time encoding to DD 5.1 and subsequent output over the optical out port. DDL is also available for all other Titanium models.
Titanium HD Mar 2010 122 dB PCIe CA20K2 64 MB optional optional Only Titanium card with no support for Windows XP. First card with THX TruStudio PC audio technology. Top quality current output Advanced Segment PCM1794A DAC. First stereo based internal Creative PCI/PCI-E sound card with gold plated RCA out since the ISA AWE64 Gold.
Creative claims it is the highest quality ever from a Creative sound card. Only available in certain markets. • SNR is 109 dB for Multi channel analog outputs and 115 dB for Stereo analog outputs. • All PCI Fatal1ty cards have 'Fatal1ty' sign with two red. PCIe Fatal1ty cards have no illuminated Fatal1ty logo and only features the X-Fi logo illuminated by two white LEDs (however it does have the Fatal1ty branding on the heatsink of the card). Elite Pro card has 'X-Fi' sign with two blue. • The I/O Console is an external box with analog and digital I/O audio jacks and volume control knobs.
It is always bundled with the remote control • The I/O Drive Box is an internal 5 1⁄ 4 drive with analog and digital I/O audio jacks and volume control knobs. Also bundled with the remote control.
• All Creative cards have 3x 1/8 inch jacks for analog headphone/speaker output (2 of them are 4-segment-jacks for a total of 7.1 sound output), some partner's cards such as Prodigy 7.1e and BRAVURA and Forte have separated headphone output. • All Creative cards except XtremeGamer have 1x shared 1/8 inch jack for either: Line In / Microphone / Digital Out / Digital I/O Module.
The optional Digital I/O Module is an external box for handling digital IO: 1x Coax In, 1x Coax Out, 1x Optical In, 1x Optical Out. The XtremeGamer card has 1x shared 1/8 inch jack for either: Line In / Microphone / Optical Out (TOSLINK minijack). It does not support the Digital I/O Module. Some partner's cards such as Prelude and Forte has separated 'Line In / Microphone' and 'Digital I/O' jack. • For the PCIe X-Fi cards, remote control support requires a USB receiver and is sold separately. • The Titanium HD lacks analog surround sound outputs. See also [ ] • • References [ ].
